Work Item customization tidbits: custom controls (part 14 of X)

In one of my previous posts I mentioned that I consider custom controls in WI one of the most complex types of customization to implement. Since I got asked related question let me expand on the topic.

Custom work item controls provide a way to implement truly specialized behavior for WI, by writing managed class conforming to well-known interface. Sometimes it may be very tempting to write the logic in C# instead of learning intricacies of WIT XML syntax (and sometimes there is no alternative).

Why is this type of customization so complex? Because you have to code, integrate, test & deploy additional component, and that in a way different from other WIT customizations in XML. And not only that - consider the following important drawbacks custom control has:

• Additional version of the control needs to be implemented if you want to support the same logic in Web UI as in Visual Studio environment
• Custom control is not supported when editing WI in Excel (or MS Project)
• Custom control assembly needs to be deployed on every client machine (or on Web server if the custom control targets Web UI)

All of the above means that custom WIT control should be implemented only when you have absolutely no other answer to outstanding business requirement.

For further information there is extensive summary article on the topic by Ognjen Bajic. Another interesting article by Neno Loje provides additional details on customizing Work Item types depending on the client (WinForms or Web), which is very relevant for custom controls.

Related posts:
- Work Item Customization: limits of complexity (part 13)
- Work Item Customization: estimate the effort (part 12)
- Work Item Customization: customization and global lists (part 11)
- Work Item Customization: customization process (part 10)
- Work Item Customization: customization tools (part 9)
- Work Item Customization: special fields (part 8)
- Work Item Customization: fields maintenance (part 7)
- Work Item Customization: global lists (part 6)
- Work Item Customization: system fields (part 5)
- Work Item Customization: user interface (part 4)
- Work Item Customization: state transitions (part 3)
- Work Item Customization: conditional field behavior (part 2)
- Work Item Customization: fields definition (part 1)

Mirror from MSDN blog

Work Item customization tidbits: limits of complexity (part 13 of X)

Today I’d like to talk about WIT customization recommendations that will mostly become applicable as your custom Work Item types increase in complexity.

Keep the number of custom fields limited (per TFS server)

One can have a maximum of 1024 fields defined per Team Foundation Server (as every field is represented by a column in SQL Server table, the limitation is that of maximum number of columns per table in SQL Server). That means that if you define new fields (FIELD with the distinct refname attribute) per WIT, you can easily hit this limit after creating a few complex Work Item types. Once the limit is reached, you have to deal with fields maintenance chores (you must delete some of the fields, and to delete them the fields must not be used in any WIT) – not a lot of fun when what you actually tried to achieve was to create new template.

How do you prevent this problem from occurring? Reuse is the key here – remember that even though it may look like you define a new field per Work Item type, fields are (precious) server resource; and even if the same field is used in WI you can specify different behavior for the same field in a different WIT.

Keep the number of rules limited (per Work Item Type)

While you can create multiple rules in WIT, be aware that rules not only affect maintenance complexity (you have to make it work ;), but also affect the performance. So your users may experience less than stellar performance when they create or modify work items. And there is an additional consideration which I will expand upon in the next section, which is called

Keep the number of WI types small (per Team project)

While there is no hard limit on the number of WIT you can create in one Team project, there is technology limitation (SQL Server again!) on how much complexity one may have per project, with numeric complexity index in this case being defined as [Number of rules in WIT] x [Number of WIT in project]. When you have too many WIT (or few of very complex ones) you may hit a limitation of maximum size of columns in SQL Server statement (65,535). It turns out all rules you define in WIT in Team project are eventually represented as part of real complex SQL statement used for WI validation when changing its data (read more techy details in this forum post by Amit Ghosh)

Keep the number of reportable fields small (per TFS server)

If you are not planning on including the fields into SQL Reporting reports, do not mark fields reportable just for the heck of it, since the reportable fields will propagate into TFS data warehouse and that would add extra in terms of performance and space on your TFS data layer.

By the way, to really understand how reporting in TFS works (and how it fits in a big picture) read this excellent post from Vince Blasberg.

In conclusion, I’d like to highlight once more the importance of having test environment whereto you deploy the potential WIT changes prior to production rollout. Consider the situation where you have just deployed new WIT to a Team project, and as a result the users cannot update any WI in the project. Not a happy place to be, is it?

Related posts:
- Work Item Customization: estimate the effort (part 12)
- Work Item Customization: customization and global lists (part 11)
- Work Item Customization: customization process (part 10)
- Work Item Customization: customization tools (part 9)
- Work Item Customization: special fields (part 8)
- Work Item Customization: fields maintenance (part 7)
- Work Item Customization: global lists (part 6)
- Work Item Customization: system fields (part 5)
- Work Item Customization: user interface (part 4)
- Work Item Customization: state transitions (part 3)
- Work Item Customization: conditional field behavior (part 2)
- Work Item Customization: fields definition (part 1)

Mirror on MSDN blog

MSBuild UsingTask gotchas

One significant drawback of MSBuild UsingTask element is that you must specify exactly the task name you are importing. That is if the assembly you are importing contains 200 tasks, you will have to import them explicitly one by one. And since you probably do not want to do that in every project you author, usually these 200 tasks will be defined in separate project file that can be imported whenever the tasks are needed.

While there is no workaround for specifying the task name, there is another, somewhat easier way to make sure that the tasks are available to your projects without explicitly importing tasks project file.

Let’s suppose that you have created MSBuild project file that contains UsingTask statements for all custom tasks you want to have available in your projects. Then if you rename this project file to have .tasks extension and place it in .NET framework folder (e.g. C:\WINDOWS\Microsoft.NET\Framework\v3.5 folder for .NET 3.5), the tasks defined there will be available in any project using that version of MSBuild without explicit import statement.

This is the mechanism used to make tasks shipped with MSBuild by default available to all projects (look into Microsoft.Common.tasks file to see these tasks defined there). No magick required!

By the way, looking into Microsoft.Common.tasks file imparts two additional pieces of wisdom (to quote):

“NOTE: Listing a <UsingTask> tag in a *.tasks file like this one rather than in a project or targets file can give a significant performance advantage in a large build, because every time a <UsingTask> tag is encountered, it will cause the task to be rediscovered next time the task is used.”

Another useful comment relates to the way the tasks are defined in UsingTask – you can either specify fully-qualified task name (including namespaces) or a short one; however, (again, quote from Microsoft.Common.tasks file):

“NOTE: Using the fully qualified class name in a <UsingTask> tag is faster than using a partially qualified name.”

In addition to performance win, you will also be able to disambiguate the task used. For example, both SDC tasks and MSBuild Community tasks packages define a bunch of tasks that differ only by name. In such cases you will have to be explicit both in UsingTask statement and when using the imported task:

<!-- Import SDC Sleep task -->

<UsingTask AssemblyFile="Microsoft.Sdc.Tasks.dll"

          TaskName="Microsoft.Sdc.Tasks.Sleep"/>

<!-- Import MSBuild Community Sleep task -->

<UsingTask AssemblyFile="MSBuild.Community.Tasks.dll"

          TaskName="MSBuild.Community.Tasks.Sleep" />

<!-- Use SDC Sleep task, full name to disambiguate -->

<Target Name="Sleep">

  <Microsoft.Sdc.Tasks.Sleep SleepTimeout="1"/>

</Target>

Mirror from MSDN blog

Branching off renamed trunk

Recently I got asked a small but unobvious branching question. Suppose you have a folder named FolderName, and for some reason you have renamed it to NewFolderName. All is well, but now you decided you want to create a branch from that folder, and to branch from the version prior to renaming.

Due to the reasons detailed in my older post, you will not be able to use branching UI for the operation. The only way to achieve that is to use tf command-line client branch command where you will explicitly specify version you branch from and the folder name at that revision

tf branch /Project/FolderName /Project/Branch /version:C123

Typical mistake people make is to use current item name, NewFolderName instead of the name that existed in the past(i.e. FolderName at the time of changeset 123).

Mirrored from MSDN blog

Work Item customization tidbits: estimating the effort (part 12 of X)

My apologies for a long silence on the subject of the series (due to several recent events) but hopefully now am back on the track and I have a long back log :)

In my previous posts I have discussed various bits that are important know before taking on Work Item types customization. Today I’d like to talk more about approaching the whole process.

I would like to advocate a conservative approach, since in most organizations (at least in my experience) there are limited resources dedicated to customization, users support and maintenance of Work Item types.

The easiest way to jump-start the customization process is to use one of the existing templates; I’d recommend stock templates coming with TFS (MSF or CMMI); however, nowadays there are other decent templates available (for example, Conchango Scrum is well known and widely used). At the very least, that provides you with minimum work item logic implemented in professional manner.

To understand the customization effort required, it is helpful to review the following:

1. Detail new data fields to be added to those existing in Work Item type; note if existing fields rules need to be modified

2. Identify the work item state lifecycle desired and how it compares with the existing one for Work Item type (mostly paying attention to the flow rather than to the states names).

3. For your new custom fields, see if there is any special logic to be implemented viz.

• Whether field rules are to be scoped by user/group
• Whether field rules are to be scoped for different states
• Whether field needs to be associated with static/dynamic list of values

Once you create mapping table of the desired vs. existing fields, these data may be used to estimate the complexity of the development & maintenance. I have tried to compile (somewhat biased) complexity list of elementary field customization task (ordered by the simplest to the most demanding):

i. New data field. Simplest customization possible both from the point of implementation and subsequent maintenance. May require additional effort if the field is to be reported on (since the integration into reports will be required)

ii. Data field with lists of values (local or global lists). For static (i.e. rarely updated) lists of values (such as priorities), both the implementation and maintenance are fairly simple. However, if the lists content is dynamic (such as customers), make sure you plan for maintenance and, more importantly, do not make any assumption as to list content in fields’ rules.

iii. Data field with static rules logic (no dependency on state/user). Since rules implemented may be pretty complex, the scenario is as complex as you made it from the point of implementation complexity. And depending on how well you test the implementation, maintenance may range from nightmare to none.

vi. Data field with rules logic dependent on state transitions. When rules are defined include dependency states lifecycle, that generally means that you need to put extra effort into testing (for large states chart the effort may be very significant) and require regression testing when the state lifecycle is modified.

v. Data field with logic dependent on user/group. When rules are scoped to specific groups (rarely to users in corporate environment), the complexity of environment may have a bearing on WIT. Namely, in Active Directory environment with multiple levels of inclusion between groups it might not be easy to diagnose why your rules function incorrectly (either from the point of being too loose or too restrictive). Extra maintenance may well be expected.

vi. Data field with custom controls. When your data field in addition to rules expressed in WI Type definition has logic defined in custom control assembly, you have just added extra dimension on implementation, testing and maintenance. That becomes even more complex task if the custom control should work for Web interface

Once you identified the work to be executed, you will be able to plan effort required for implementation, testing, deployment and maintenance.

In conclusion, I’d like to highlight two very important principles which when followed will prevent a plethora of issues: a) never deploy to production before deploying to test environment and b) plan and execute the whole WI Types customization process as if it was an ordinary software development effort.

Related posts:
- Work Item Customization: customization and global lists (part 11)
- Work Item Customization: customization process (part 10)
- Work Item Customization: customization tools (part 9)
- Work Item Customization: special fields (part 8)
- Work Item Customization: fields maintenance (part 7)
- Work Item Customization: global lists (part 6)
- Work Item Customization: system fields (part 5)
- Work Item Customization: user interface (part 4)
- Work Item Customization: state transitions (part 3)
- Work Item Customization: conditional field behavior (part 2)
- Work Item Customization: fields definition (part 1)

Mirror from MSDN blog

TFS Administrator chores – space offender strikes again!

In my previous post I talked about management of large files in TFS version control database. Today I’d like to talk about what you can do to optimize space management in work item tracking database.

As you know, it is possible to add file attachments to Work Item, with the maximum attachment size of 2Mb (by default); but most people who use attachments with WI change that limit to something larger (this MSDN article details how to change the maximum attachment size), since default frequently does not suffice for video captures and such.

Which naturally brings us to the question – if the maximum size set, say, to 32 Mb, how could one prevent misuse of the attachment feature?

There is nothing in Team Explorer UI to help you with figuring out the size of the added attachment; and nothing to prevent a user from adding however many large attachments (if they are not greater than maximum size). That leaves you with user education as a form of prevention; and to report the usage it is possible to run raw SQL on the relational database (all of the below queries are strictly AS IS etc.):

-- Query WIT database

USE TfsWorkItemTracking;

SELECT

    -- parent work item

    ID AS WorkItemID,

    -- name of the attachment file

    OriginalName AS AttachementName,

    -- attachment comment

    Comment,

    -- file size

    [Length] AS [Size],

    -- whether attachment was deleted

    CASE WHEN RemovedDate = '01/01/9999' THEN 0

              ELSE 1 END AS Deleted

FROM WorkItemFiles

    WHERE

    -- File attachments only

    FldID = 50

    -- return only large files

    AND    [Length] > @LargeFile

The query will give you the list of WI with large attachments, so you could figure out whether this feature is used in a sensible way.

If you look at the query closely, you’ll notice that the attachment in the database can be removed from WI and still exist in the database. What does that mean, say you? Whereas with version control one can delete item (where the item still will be in DB) and then destroy it (where item will be purged from DB), there is no such feature with Work Item attachments.

It turns out when you delete attachment from Work Item, the actual content is never deleted from database unless you do it manually. There is even helpful but incredibly well-hidden and vague article in MSDN on the subject, titled “How to: Delete Orphaned Files Permanently”.

That means even if you have managed to delete large attachments from WI, your job to recover the space is still half-done, and you need to actually delete the attachment content from the database.

The query below will enumerate all orphaned (deleted from Work Items, but still in DB) attachments, whereas subsequent query can be used to actually purge the deleted items from the database.

-- Query for all orphaned attachments

SELECT WorkItems.ID AS WorkItemID,

        WorkItems.OriginalName AS AttachementName,

        WorkItems.Comment

FROM TfsWorkItemTrackingAttachments.dbo.Attachments Attachements,

        TfsWorkItemTracking.dbo.WorkItemFiles WorkItems

    WHERE Attachements.FileGuid = WorkItems.FilePath

        AND WorkItems.RemovedDate <> '01/01/9999'

        AND WorkItems.FldID = 50

-- When absolutely sure - delete the orphans

DELETE

    FROM TfsWorkItemTrackingAttachments.dbo.Attachments

-- join to WIT tables to identify orphans

WHERE FileGuid IN (SELECT FilePath

        FROM TfsWorkItemTracking.dbo.WorkItemFiles

        WHERE RemovedDate <> '01/01/9999'

        AND FldID = 50)

Purging orphans seems to me a good candidate for the recurring job (not sure why it is not part of core TFS setup).

Mirrored from MSDN blog

TFS Administrator chores – dealing with the space offender

These are the days of cheap storage - but even the cheap storage may run out. And running Team Foundation Server storing artifacts in its (multiple) databases may use up your space rack faster than you might have expected (and if you want to know what to expect, refer to this classical post by Buck Hodges on database size calculations).

If that happens, the most probable culprit is version control database (TfsVersionControl) – in other words, all these files that people check in into version control. The size of the file matters because TFS stores difference only for each new revision of “small” files but for the “large” files every new revision gets full-blown copy (by default TFS considers the file to be large if it is over 16 Mb - read more on that topic in my previous post).

There are several ways of making sure that your users do not fill up your version control with memory dumps, images of installation CDs and such. Mind you – I am not saying that large files do not belong to version control; I am saying that the addition of large files should be a) conscious step and b) “revisionless” (i.e. with no versioning).

Myself, I have been always ambivalent about storing large binary thingies in source control – on one hand, you get all content in one place (which is mighty convenient for builds etc.), on the other hand, many users will probably check in the content that does not belong in source control. So here is my hit list of  measures to deal with large files in version control

• Educate your user – make sure your average user understands that DVD ISO added to version control ends up being transmitted and stored in the database; perhaps what the user is looking for is file server, not version control
• Make user aware of his actions – it is possible to write check-in policy that would alert the user at the time of check-in, that the files being checked in are large and perhaps should not be in version control. And then, even if the user decides to override the policy you may run report on policy overrides
• Monitor your storage – if high level prevention and low level prevention fail, you can query the database to identify the offending files. The query below (with usual caveats – it is AS IS etc.) will give you a list of large files in the database (it will not take into account the summary size of all versions, only the latest version):

DECLARE @LargeFile int;

-- return files larger than 16 Mb

SET @LargeFile = 16 * 1024 * 1024;

USE TfsVersionControl; –– use source control DB

SELECT -- item path

    Versions.ParentPath + Versions.ChildItem AS ItemPath,

    -- size of latest version in DB

    Files.CompressedLength AS DatabaseSize,

    -- size of original file

    Files.FileLength AS [Size],

    -- whether item deleted

    CASE WHEN Versions.DeletionId = 0 THEN 0

        ELSE 1 END AS Deleted

FROM tbl_File Files, tbl_Version Versions

WHERE -- get item latest version

    Versions.VersionTo = 2147483647

    -- join to table with sizes

    AND Versions.FileId = Files.FileId

    -- return only large files

    AND Files.CompressedLength > @LargeFile

ORDER BY ItemPath;

I would be happy to hear your horror stories of the application of the above query; mine was nothing more than a bunch of ISO images checked in :)

Thanks for reviewing the query go to Chandru Ramakrishnan

Mirrored from MSDN blog

Moving on

As you might now, from November ‘08 I am working at Microsoft, and as every MS employee I am now entitled to Community Server powered blog at blogs.msdn.com (mine is http://blogs.msdn.com/eugenez).

Though Blogger is a convenient platform, Community Server is ways better, and thus I will be making MSDN my new [blog] home. So update your reader with the new feed! But if you don’t – do not worry, I will be mirroring TFS related posts here.

See you around!

Something good to read

This is a short post to let you know that there is one new blog of note that you should add to your RSS reader. Welcome (back) Richard Berg, blogging about TFS,  PowerShell and more at http://www.richardberg.net/blog. Until recently, Richard used to work at Microsoft, and if you ever asked a question at MSDN TFS Version Control forum, you probably had it answered  by Richard.

His new blog already has a whole lot of information about TFS PowerShell cmdlets, so stay tuned for more!

TFS Code Review Tools digest

If you are interested in getting most out of your TFS toolset, an extensive summary presentation on Code Review tools in TFS domain is available from JB Brown. I had a pleasure of watching the presentation in person, and it covers most alternatives available.

For those who do not know, JB Brown is the original author and main contributor for TeamReview project. TeamReview allows performing collaborative code reviews using less than traditional approach (see a good intro post on how it works by Willy-Peter Schaub ), where you can actually replay the steps performed in code review (and it stores the code review comments using TFS work items).
